led and solar lights
| Body | Die-casting aluminum body | Input Voltage | 220-240V | Frequency（Hz） | 50 – 60 |
| LED | Lumileds / Cree / Osram | CRI | >70Ra | IP Rate | IP66 |
| Lens | Modular Optical Lens | Power | >0.95 | RAL Code | Customized |
| Diffuser | PC diffuser | Working Temp. | -35℃-+55℃ | Options | LED application according to desired correlated color temperature(CCT). |
| Driver | PHILIPS /MEANWELL / OSRAM / INVENTRONICS | Humidity | 10% – 90% |
Lighting Distribution Curve
Technical Drawing
Product Details
| Product Code
NO |
Power
W |
Luminous Flux
lm |
Color Temp.
K |
Luminous Effic
lm/W |
Dimensions
H*W(mm) |
Pcs/Pack | Package
(mm) |
|---|---|---|---|---|---|---|---|
| LSG01-30 | 30 | 3600-4500 | 2200-6500 | 120-150 | 580*Φ470 | 1 | 485*485*610 |
| LSG01-40 | 40 | 4800-6000 | 2200-6500 | 120-150 | 580*Φ470 | 1 | 485*485*610 |
| LSG01-50 | 50 | 6000-7500 | 2200-6500 | 120-150 | 580*Φ470 | 1 | 485*485*610 |
| LSG01-60 | 60 | 7200-9000 | 2200-6500 | 120-150 | 580*Φ470 | 1 | 485*485*610 |
| LSG01-70 | 70 | 8400-10500 | 2200-6500 | 120-150 | 580*Φ470 | 1 | 485*485*610 |
